Operation
21 F232101
Table 1 (Continued)
Display Interpretations
Display Meaning Display Meaning
STOP Stop button pressed or cycle ended WE-6 Prompts
S1 Supply #1 (Detergent) °FAR Temperature in degrees Fahrenheit
S2 Supply #2 (Bleach) °CEN Temperature in degrees Centigrade
S3 Supply #3 (Sour) 1DRAIN One drain capability selected. (This means
that a second independent drain controlled by
Auxiliarry 2 output is disabled.)
S4 Supply #4 (Softener) 2DRAIN Second independent drain enabled (via
Auxiliary 2 output – precludes control of
recirculation pump via Auxiliary 2, if
selected). This should not be confused with
the “dual drain” option.
S5 Supply #5 (Starch/Sizing)
TH Controlled temperature fill to high level
TM Controlled temperature fill to medium level
TL Controlled temperature fill to low level ADV Advance (skip steps) feature enabled
TO Controlled temperature overflow NO ADV Advance feature disabled
WH Warm fill to high level MANUAL Manual Mode enabled
WM Warm fill to medium level NO MAN Manual Mode disabled
WL Warm fill to low level WET CL Wet clean function for Auxiliary 1 output
(1/2 wash speed) and Auxiliary 2 output
(recirculation pump) enabled. (Refer to
“2DRAIN”.)
WO Warm fill to overflow level
W1 Wash 1 (regular reversing)
W2 Wash 2 (gentle reversing) NO WCL Wet clean function for Auxiliary 1 and 2
disabled (Auxiliary 1 and 2 are timed
outputs).
W3 Wash 3 (no agitation)
W4 Wash 4 (medium reversing action) BAL SW Balance sensor
W5 Wash 5 (temp.-controlled cool-down) BAL 1 Balance routine for 1305 inverter drive
W6 Wash 6 (extra low agitation) BAL 2 Balance routine for 1336 inverter drive for
135-pound capacity
W7 Wash 7 (no agitation, drain 1 open, no refill)
• Left dot – poor balance condition BAL 3 Balance routine for 1336 inverter drive for
250-pound capacity
• Second dot from left – door lock switch
• Third dot from left – Program Mode
• Fourth dot from left – high level reached
• Fifth dot from left – medium level reached
• Right dot – low level reached
