Chapter 5 Jumper Settings and Connectors 47
5.1.4 Connectors
On-board connectors link the panel PC to external devices such as hard
disk drives or floppy drives. The table below lists the function of each of
the board’s connectors.
Table 5-2: Panel PC connectors
Label Function
J1 IR connector
J2 Flat panel display connector
J3 Flat panel display connector
J4 Internal COM4 connector
J5 Touchscreen power connector
J6 Sandisk SSD connector
J7 EIDE hard disk driver connector
J8 Floppy driver connector
J9 CD-ROM connector
J10 CPU fan power connector
J11 PCI/ISA bus expansion connector
J12 Fan power connector
J13 AT power connector
J14 ATX power connector (Reserved)
J15 Internal speaker connector
J16 Inverter power connector
