140 PPC-120/140 User's Manual
Table A-1: PPC-120/140 series LCD specifications
* The VR control knobs are located on the I/O section on the rear cover of
the panel PC.
Note: The color LCD display installed in the panel PC is
high-quality and reliable. However, it may contain a few
defective pixels which may not always illuminate. With
current technology, it is impossible to completely
eliminate defective pixels. Advantech is actively working
to improve this technology.
Model PPC-140T PPC-140S PPC-120T
Display type
(LCD)
13.8" TFT 13.8" DSTN 12.1" TFT
Max. resolution 1024 x 768 1024 x 768 800 x 600
Colors 256 K colors 256 K colors 256 K colors
Dot size (mm) 0.33 x 0.33 0.33 x 0.33 0.33 x 0.33
View angle 120° 90° 120°
Luminance 250 cd/m² 200 cd/m² 250 cd/m²
Temperature 0° ~ 50° C 0° ~ 40° C 0° ~ 50° C
*VR controls *Brightness
*Brightness/
Contrast
*Brightness
Simultaneous
mode
Yes Yes Yes
LCD MTBF 50,000 hours 50,000 hours 50,000 hours
Backlight MTBF 25,000 hours 25,000 hours 25,000 hours
