174 PPC-120/140 User’s Manual
E.3 Desktop Stand Mounting
The PPC-120/140 has a customized stand suitable for desktops and other
horizontal locations. A unique spring inside the stand enables the panel
PC’s vertical tilt to be adjusted about 30 degrees. The stand is available
from Advantech Co.
Follow these procedures to set up the stand:
1. Remove the rear cover of the panel PC by unscrewing the seven
screws.
2. Attach the holding plate of the stand to the inside of the rear cover of
the panel PC using the five screws provided. (See Fig. E-3.)
3. Reattach the rear cover of the panel PC.
4. Attach the main body of the stand to the rear cover of the panel PC
using the four screws provided.
5. Slide the main body of the stand into the stand base. Tighten it with the
two screws provided.
6. Attach the rear cover of the stand to the main body of the stand by
snapping the lugs of the rear cover into the slots of the main body.
When the rear cover locks into place, you will hear a click.
7. Attach the top cover of the stand to the main body of the stand by
snapping the lugs of the top cover into the slots of the main body. The
cover must be rotated as it is snapped into place. When the top cover
locks into place, you will hear a click.
Note: The base of the stand has two plastic caps. If you pry
off the caps, you can attach the stand to your desktop
using the two screw holes.
