2.2.5 2.2.5 2.2.5 2.2.5 2.2.5 Layout contents Layout contents Layout contents Layout contents Layout contents
S l o t s S l o t s S l o t s S l o t s S l o t s P a g e P a g e P a g e P a g e P a g e
1. DDR2 DIMM slots 2-14
2. PCI slots 2-18
3. PCI Express slot 2-20
J u m p e r s J u m p e r s J u m p e r s J u m p e r s J u m p e r s P a g e P a g e P a g e P a g e P a g e
1. Clear RTC RAM (3-pin CLRTC1) 2-21
2. USB Device wake-up (3-pin USBPW12, USBPW34, 2-22
USBPW56, USBPW78)
3. Keyboard power (3-pin KBPWR1) 2-22
R e a r p a n e l c o n n e c t o r s R e a r p a n e l c o n n e c t o r s R e a r p a n e l c o n n e c t o r s R e a r p a n e l c o n n e c t o r s R e a r p a n e l c o n n e c t o r s P a g e P a g e P a g e P a g e P a g e
1. Parallel port 2-23
2. IEEE 1394a port 2-23
3. LAN (RJ-45) port 2-23
4. Rear Speaker Out port (gray) 2-23
5. Side Speaker Out port (black) 2-23
6. Line In port (light blue) 2-23
7. Line Out port (lime) 2-23
8. Microphone port (pink) 2-24
9. Center/Subwoofer port (yellow orange) 2-24
10. USB 2.0 ports 3 and 4 2-24
11. USB 2.0 ports 1 and 2 2-24
12. Optical S/PDIF Out port 2-24
13. Coaxial S/PDIF Out port 2-24
14. PS/2 keyboard port (purple) 2-24
15. PS/2 mouse port (green) 2-24
