MAINS CONNECTION
Connect only to single-phase AC system voltage as indicated on
the rating plate. It is also possible to connect to sockets without an
earthing contact as the design conforms to safety class II.
Appliances used at many different locations including wet room
and open air must be connected via a residual current device (FI,
RCD, PRCD) of 30mA or less.
Only plug-in when machine is switched off.
Do not let any metal parts enter the airing slots - danger of short
circuit!
WS 22-180, WS 22-230, WS 24-230 GV: Inrush currents cause
short-time voltage drops. Under unfavourable power supply
conditions, other equipment may be affected. If the system
impedance of the power supply is lower than 0,2 Ohm, disturbances
are unlikely to occur.
SPECIfIED CONDITIONS Of USE
The angle grinder is intended for grinding and cutting metal, stone
and ceramic materials as well as sanding and wire brushing.
Use the cutting guard from the accessories range for cutting
application.
Please refer to the instructions supplied by the accessory manuf-
acturer.
The machine is suitable only for working without water.
WORKING TIPS
For accessories intended to be fitted with threaded hole wheel,
ensure that the thread in the wheel is long enough to accept the
spindle length.
Always use and store the cutting and grinding disks according to
the manufacturer‘s instructions.
Always use the correct guard for cutting and grinding.
The grinding surface of the centre depressed disks must be moun-
ted min. 2 mm below the plane of the guard lip.
The adjusting nut must be tightened before starting to work with
the machine.
Always use the auxiliary handle.
The workpiece must be fixed if it is not heavy enough to be steady.
Never move lead the workpiece towards the rotating disk by hand.
RESTART CUTOUT
WS 22-180 E, WS 22-230 E, WS 24-230 GEV:
Machines with a lockable switch are supplied with a restart cutout.
This prevents the machine restarting by itself after a power failure.
When resuming work, switch the machine off and then switch it
back on again.
STARTING CURRENT LIMITER
WS 22-180 E, WS 22-230 E, WS 24-230 GEV:
The starting current for the machine is several times greater than
rated current. The starting current limiter reduces the starting cur-
rent to such an extent that a fuse (16 A, slow-blow) is not tripped.
SMOOTH START
WS 22-180 E, WS 22-230 E, WS 24-230 GEV:
Electronic smooth start for save use prevents jerky run-up of the
machine.
MAINTENANCE
The ventilation slots of the machine must be kept clear at all times.
If the supply cord of this power tool is damaged, it must be
replaced by a specially prepared cord available through the service
organization.
Use only AEG accessories and spare parts. Should components need to
be replaced which have not been described, please contact one of our
AEG service agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please
state the machine type printed as well as the six-digit No. on the
label and order the drawing at your local service agents or directly
at: Techtronic Industries GmbH, Max-Eyth-Straße 10, 71364 Win-
nenden, Germany.
EC-DECLARATION Of CONfORMITy
We declare under our sole responsibility that the product described
under “Technical Data” fulfills all the relevant provisions of the direc-
tives 2011/65/EU (RoHs), 2004/108/EC, 2006/42/EC and the following
harmonized standards have been used:
EN 60745-1:2009 + A11:2010
EN 60745-2-3:2011 + A2:2013
EN 55014-1:2006 + A1:2009 + A2:2011
EN 55014-2:1997 + A1:2001 + A2:2008
EN 61000-3-2:2006 + A1:2009 + A2:2009
EN 61000-3-3:2008 (WS 22-180 E, WS 22-230 E, WS 24-230 GEV)
EN 61000-3-11:2001 (WS 22-180, WS 22-230, WS 24-230 GV)
Winnenden, 2013-10-30
Alexander Krug / Managing Director
Authorized to compile the technical file
Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364 Winnenden, Germany
SyMBOLS
CAUTION! WARNING! DANGER!
Please read the instructions carefully before starting the
machine.
Always wear goggles when using the machine.
Wear gloves!
Always disconnect the plug from the socket before
carrying out any work on the machine.
Do not use force.
Only for cutting work.
Only for grinding.
