Projector Resolution Mode Aspect
ratio Refresh rate
(Hz) Horizontal
frequency
(kHz) Pixel clock
(MHz)
SMART UF75w
(16:9 aspect ratio
mode) 1280 × 720 WXGA 16:9 60 48 83.5
Video format compatibility
The following tables list the projectors’ compatible VESA RGB video formats by resolution, which the
projector adjusts automatically when you use the aspect ratio commands described in Adjusting
projector settings on page 24.
The following tables list the projectors’ compatible VESA RGB video formats by resolution, which the
projector adjusts automatically when you use the aspect ratio commands described in Adjusting
projector settings on page 24.
SMART UF75 projector
Resolution Mode Aspect ratio Refresh rate (Hz) Match Input
appearance
720 Ч 400 720Ч400_85 1.8:1 85.039 Letterbox
640 × 480 VGA 60 4:3 59.94 Full screen
640 × 480 VGA 72 4:3 72.809 Full screen
640 × 480 VGA 75 4:3 75 Full screen
640 × 480 VGA 85 4:3 85.008 Full screen
800 × 600 SVGA 56 4:3 56.25 Full screen
800 × 600 SVGA 60 4:3 60.317 Full screen
800 × 600 SVGA 72 4:3 72.188 Full screen
800 × 600 SVGA 75 4:3 75 Full screen
800 × 600 SVGA 85 4:3 85.061 Full screen
832 × 624 MAC 16" 4:3 74.55 Full screen
1024 × 768 XGA 60 4:3 60.004 Full screen
1024 × 768 XGA 70 4:3 70.069 Full screen
1024 × 768 XGA 75 4:3 75.029 Full screen
1024 × 768 XGA 85 4:3 84.997 Full screen
1024 × 768 MAC 19" 4:3 74.7 Full screen
1152 × 864 SXGA1 75 4:3 75 Full screen
1280 × 768 SXGA1 75 1.67:1 60 Letterbox
1280 × 800 WXGA 16:10 60 Letterbox
1280 × 800 WXGA 16:10 58.2 Letterbox
C H A P T E R 5
Integrating other devices
42
