CHAPTER 4
Performing Advanced Functions
46
Following notification types can be returned when issuing the
RNTTL command:
R ETURNS The return result depends on the control byte (see table). However,
whatever the return result is, it includes the control byte.
R EMARKS The general behavior is that an ANLG command issued on a cer-
tain input channel will override any previous ANLG commands
affecting that channel.
R EMOTE The A723 device cannot issue ANLG commands remotely, but can
execute them.
E XAMPLE For RSM
ANLG 0
9999 ANLG 0 5 5 5 5 5 5 5 5 4 4 5 5 0
#
For SSMAA (on channel 4)
ANLG 68
9999 ANLG 68 0
#
For DAN (on channel 0)
ANLG 160
9999 ANLG 160 0
#
For RNTTL (on channel 2)
ANLG 178
9999 ANLG 178 340 3900 0
#
For ENOPTR (on channel 10)
ANLG 202 1000
9999 ANLG 202 0
#
C OMMAND PORT
Value Notification Type
00 Notify On Positive Threshold.
01 Notify On Negative Threshold.
10 Notify if Out of Limits.
11 Notify if Inside the Limits.
