Configuring the Printer 3-22
Default Gateway* If a router is used on the network, sets the router’s
address.
Range: 0–255 for each xxx triplet
Default: 192.168.1.1
If the router address is outside the range, the following
message displays when you choose the Apply button:
“Update unsuccessful. The address entry is incorrect.
Please go back to the previous page.” Choose the
browser’s Back button and then type an appropriate
number.
Configuration Menu Equivalent: Network/Gateway
RAW Port
Number Identifies the number of the printer’s RAW port.
Choices: Non-configurable
Default: 9100
Apply button Applies the configuration settings for this window.
Clear button Resets all configuration settings for this window to their
factory defaults.
Log-out button Logs out of Administrator Mode and returns to User
Mode.
* Always enter these addresses without leading zeros. For example,
131.011.010.001 should be entered as 131.11.10.1.
Item Description
