ARTURIA – JUPITER-8V – USER’S MANUAL 80
The Galaxy module
7.4 V OICE E FFECTS
The Jupiter-8V offers two connections of “Voice” effects. These connections can be made
inside the synthesis chain, between the VCO and the VCF and between the VCF and the
VCA.
These effects can be modulated by sources of modulation such as the LFO or the
envelopes. These combinations of effects and of modulations will bring an additional
dimension to the original sound of the Jupiter-8.
Connections of the voice effects
The effects are accessible when you click on the “EFFECTS” tab, situated on the LCD
screen, on the right part of the Jupiter-8V. They will be activated or deactivated when
you click on the “EFFECT” button, situated on the toolbar.
7.4.1 Chorus /Flanger
This monophonic Chorus/Flanger module adds a comb filtering aspect to the sound.
RATE Knob to set the frequency of the chorus
DEPTH Knob to set the depth of the modulation
FEEDBACK Knob to set the feedback of the modulation. (to achieve more of a flanged
effect)
AMOUNT Knob to set the depth of the modulation
DRY/WET Knob to set the balance between the original signal and the output of the
effect
OUTPUT Knob to set the output volume of the chorus
The “MOD” display allows accessing the modulation connections of each of the
parameters of the chorus as well as the choice of the sources of modulation:
