Apple iMac G5 User Manual
Page 46
46
Chapter 4
Enhancing Your Computer
8
Turn the three captive screws clockwise to tighten them. Be careful not to over-tighten
the screws, as you may strip the screw heads.
9
Holding each side of the computer, gently turn the computer right side up. Then
reconnect the cables and power cord you disconnected from your computer.
10
Press the power button on the back of your computer to turn it on.
·
Warning:
The ambient light sensor is located to the left of the middle screw, as
shown in the illustration. Don’t mistake the ambient light sensor for a screw. Sticking
a screw driver or other sharp object in the ambient light sensor could damage your
computer.
Warning:
Operating the computer when it is open or missing parts can be dangerous
and could damage your computer.
Raise
stand
Phillips
screwdriver
Tighten 3
screws
Screw
Ambient
light sensor
