2-2 Mounting positions and image view area
Wide picture
Zoom picture
The zoom position can be changed.
(Refer to the master station's operation manual.)
The factory setting is "Center " for Zoom mode.
Approx.
1,050 mm
(3' 5")
Approx. 700 mm (2' 3")
Approx. 900 mm (3')
Objects appear smaller due
to greater distortion in the
surrounding sections compared
to the central section, but a
wider area is displayed.
The display range is a rough
estimation and may change
due to the installation
environment.
Wide picture
Up/Down
Mounting position
1,500 mm (5')
Left/Right
Approx. 1,050 mm (3' 5")
Approx. 2,000 mm
(6' 7")
Approx. 950 mm
(3' 2")
500 mm (20")
1,500 mm (5')
Unit center
Approx. 1,800 mm
(5' 11")
Approx. 1,050 mm (3' 5")
Approx. 750 mm
(2' 5")
Mounting position
1,300 mm (4' 3")
Unit center
1,300 mm (4' 3")
500 mm (20")
Approx. 170
Zoom picture (when mounting position is 1,500 mm (5'))
Left/Right
Up/Down
500 mm (20")
Zoom
Approx. 850 mm (2'9")
Approx. 1,400 mm
(4' 7")
500 mm (20")
Unit center
1,500 mm (5')
Approx. 700 mm
(2' 3")
Approx. 1,150 mm
(3' 9")
Zoom Zoom
Approx. 1,600 mm
(5' 4")
Approx. 850 mm
(2' 9")
500 mm (20")
Unit center
1,500 mm (5')
Zoom Zoom Zoom
500 mm (20")
500 mm
(20")
Approx. 100 mm (4")
Approx.
1,300 mm (4' 3") Approx. 900 mm (3')
Approx.
1,300 mm (4' 3") Approx. 100 mm (4")
Unit center
1,500 mm (5')
500 mm (20")
2-3 cable
1
PVC jacket with PE (polyethylene) insulated cable is
recommended.
2
Never use individual conductors, twisted pair cable or coaxial
cable.
2
JK-1MD JK-DA JK-DV JK-DVF JK-1MED
2-4 Wiring distance
M S D
A
A
2
JK-1MED
JK-1MD
JK-1MED
JK-1MD
4
JK-DV JK-DA JK-DVF
JK-DV JK-DA JK-DVF
JK-1HD
2
JK-1SD
Ø 0.65 mm 22 AWG Ø 1.0 mm 18 AWG
A 50 m 165' 100 m 330'
An area over a range of approx. 170 in a 500
mm radius from the camera displays.
(The display range is a rough estimation
and may change due to the installation
environment.)
Approx. 2,250 mm
(7' 5")
Approx. 1,850 mm
(6' 1")
Approx. 750 mm
(2'5")
500 mm (20")
