Chapter 1. Product overview

This chapter provides an overview of the tablet, including the locations of the connectors and controls, tablet
features, accessories, specifications, and operating environment.

Tablet layout

This topic introduces the tablet hardware features to give you the basic information you will need to start
using the tablet.

Front and side view

Figure 1. ThinkPad Tablet 2 front and side view

1

Tablet Digitizer Pen storage

9

ThinkPad Tablet 2 Dock connector

2

SIM-card slot

10

Emergency-reset hole

3

Micro SD card reader

11

dc-in connector

4

Power button

12

USB connector

5

Headphone or microphone connector

13

Front-facing camera

6

Volume control buttons

14

Ambient light sensor

© Copyright Lenovo 2012, 2013

1
