a. Press the release tab 1 in the direction as shown, and then carefully lift the PCI card bracket
assembly slightly upward until the two mounting studs 2 on the chassis are in the central position of
the corresponding holes in the PCI card bracket assembly.
Figure 38. Releasing the PCI card bracket assembly
b. Carefully move the PCI card bracket assembly to the top side of the chassis until the PCI card
bracket assembly is released from the mounting studs on the chassis. Then, lift the PCI card bracket
assembly out of the chassis.
Figure 39. Removing the PCI card bracket assembly
