FleetFit Vehicle Push-In Fittings
Dimensions in Inches (mm)
Side Tee Adapters
NPT, NPT Female
E
F
G
C
D
B
H
A
J
A
C
Tube
B
NPT
Product
O.D.
NPT
Female
Number
D
E
F
G
H
J A/F
3⁄8"
1⁄4"
1⁄4"
95 4587 01
0.34
1.93
0.96
0.56
1.08
0.71
(8.7)
(49.0)
(24.5)
(14.3)
(27.5)
(18.0)
Male Swivel Run Tees
NPT
D
E
F
B
H
A
C
A
C
G
Note: The Swivel feature should be used for positioning purposes only and
should not be used as a rotating joint.
A
Tube
B
Product
O.D.
NPT
Number
ØC
D
E
F
G
H A/F
1⁄4"
1⁄8"
95 4112 04
0.51
1.75
0.91
0.37
0.83
0.43
(13.0)
(44.4)
(23.2)
(9.5)
(21.2) (11.0)
1⁄4"
1⁄4"
95 4112 10
0.51
1.95
1.12
0.56
0.83
0.55
(13.0)
(49.6)
(28.4)
(14.3)
(21.2) (14.0)
3⁄8"
1⁄4"
95 4112 12
0.67
2.36
1.29
0.56
1.07
0.75
(17.0)
(60.0)
(32.7)
(14.3)
(27.3) (19.0)
3⁄8"
3⁄8"
95 4112 20
0.67
2.32
1.24
0.56
1.07
0.75
(17.0)
(58.9)
(31.6)
(14.3)
(27.3) (19.0)
3/8''
1/2''
95 4112 29
0.67
2.50
1.44
0.75
1.07
0.87
(17.0)
(64.1)
(36.8)
(19.1)
(27.3) (22.0)
1/2''
1/4''
95 4112 13
0.81
2.15
1.27
0.56
1.27
0.87
(20.6)
(54.5)
(32.2)
(14.3)
(32.3) (22.0)
1⁄2"
3⁄8"
95 4112 21
0.81
2.69
1.42
0.56
1.27
0.87
(20.6)
(68.4)
(36.1)
(14.3)
(32.3) (22.0)
1⁄2"
1⁄2"
95 4112 30
0.81
2.89
1.62
0.75
1.27
0.87
(20.6)
(73.4)
(41.1)
(19.1)
(32.3) (22.0)
Special Tee Adapters
NPT Female, NPT
D
E
B
F
G
C
A
H
A
B
Tube
NPT
C
Product
O.D.
Female
NPT
Number
D
E
F
G
H A/F
1⁄2"
1⁄4"
1⁄4"
95 4563 01
1.22
0.75
1.14
0.56
0.87
(31.0)
(19.0)
(29.0)
(14.3) (22.0)
1/2''
1/4''
3/8''
95 4563 02
1.30
0.75
1.14
0.56
0.87
(33.0)
(19.0)
(29.0)
(14.3)
(22.0
Special Hobbs Side Tee Adapters
Metric, NPT Female
E
G
C
F
B
A
D
J
H
A
C
Tube
B
NPT
Product
O.D.
Thread
Female
Number
ØD
E
F
G
H A/F J A/F
3⁄8" M22 x 1.5
1⁄4"
95 4423 01
0.79
2.74
0.98
0.87
1.18
1.18
(20.0)
(69.5)
(25.0)
(22.0)
(30.0) (30.0)
SAE 6308AB
