Configuring the Lucid ADA 88192 Converter
35
Lucid ADA 88192 Converter Settings for Remote Control
You must configure the following settings to control the converter remotely. Any setting not
listed here either has no effect with the application or can be set through the audio preferences
of the application.
Lucid ADA 88192 Converter Settings for Local Control
You must configure the following settings to control the converter locally. Any setting not listed
here either has no effect with the application or can be set to any of the values available for it.
Menu Menu Item Comment
ADAT ADAT INs: SRC ON
ADAT INs: SMUX OFF
AES AES IN1+2: SRC OFF
AES IN3+4: SRC OFF
AES IN5+6: SRC OFF
AES IN7+8: SRC OFF
Analog
Analog INs: SoftClip IN1+2: SoftClip OFF
IN3+4: SoftClip OFF
IN5+6: SoftClip OFF
IN7+8: SoftClip OFF
Meter Clip Detect: 3 3 is the recommended setting
System
Miscellany Route Unit: 8 8 is the recommended setting
Menu Menu Item Comment
ADAT ADAT INs: SRC ON
ADAT INs: SMUX OFF
AES AES IN1+2: SRC OFF
AES IN3+4: SRC OFF
AES IN5+6: SRC OFF
AES IN7+8: SRC OFF
Analog
Analog INs: SoftClip IN1+2: SoftClip ON
IN3+4: SoftClip ON
IN5+6: SoftClip ON
IN7+8: SoftClip ON
Analog
Analog INs: Gain set each input channel to a
value in the range
-95.5 to +31.5 dB
Analog
Analog OUTs: Level set either -10 or +4 for each
output channel
Meter Clip Detect: 3 3 is the recommended setting
