Connecting Peripherals
2
18
Connecting the Keyboard, Mouse, and Tablet
Connect the keyboard, mouse, and tablet to the USB extender and the Linux workstation before
booting the workstation and before installing the application.
The Wacom® Intuos USB tablet is shipped with your system. All customization with respect to
the tablet, including setting tablet margins, should be done in the Preferences menu of your
HP xw9400 Workstation
To DVI-Ramp2 control
To keyboard, mouse,
USB tablet
Graphics monitor sync
reference input
To storage
AJA OEM-2K
To Wire network
(Infiniband option available)
To house network
NVIDIA graphics to
DVI-Ramp2
