Setting Up Video Hardware

3

28

1
6
2
7
3
8
4
9
5

1
6
2
7
3

8
4
9
5

WHT

BLK

BLK

RED

GND

2 - RX -

7 - RX +

8 - TX -

3 - TX+

8 - TX -

3 - TX +

2 - RX -

7 - RX+

4 - GND (SHIELD)

4 - GND (SHIELD)

PAIR 1

PAIR 2

VTR-Emulation Control Cable:

Linux(AJA) Master Controlling Linux(AJA)

Emulator

Linux(AJA) Master

Linux(AJA) Emulator

OEM-2K: MALE DB9

OEM-LH: FEMALE DB9

OEM-2K: MALE DB9

OEM-LH: FEMALE DB9
