N/en 4.3.007.02
M/50/EAP & M/50/EAN
1999-4001c
1/14
Our policy is one of continued research and development. We therefore reserve the right to amend,
without notice, the specifications given in this document. © 2014 Norgren GmbH
Plug-in connector cable with nut
Outer cover Cable length Weight (kg) Connector
Model
PVC 3 x 0,25
5 m
0,18
M8 x 1
M/P73001/5
PUR 3 x 0,25
5 m
0,18
M8 x 1
M/P73002/5
PUR 3 x 0,34
5 m
0,21
M12 x 1
M/P34594/5
Accessories
Mounting elements for magnetic switches
Switching current and switching voltage
150
0
30
V
4,5 W
mA
Cylinder with external tie rods
RA/8000/M, KA/8000/M
RA/28000/M, RM/900/M
Roundline cylinder
RM/55401/M
Roundline cylinder
KM/55001/M, VSM/55640/N2
Roundline cylinder
R./57100/M, R./57200/M
R./57300/M
Roundline cylinder
< 25 mm stroke
RM/8000/M, KM/8000/M
RM/28000/M
Roundline cylinder
> 25 mm stroke
RM/8000/M, KM/8000/M
RM/28000/M
Mounting elements
Cylinder
Ø(mm) Model
Cylinder
Ø(mm) Model
Cylinder
Ø(mm) Model
Cylinder
Ø(mm) Model
Cylinder
Ø(mm) Model
Cylinder
Ø(mm) Model
32 ... 200 QM/27/2/1
32
QM/33/432/22
32
QM/33/432/22
10
QM/33/010/22
10
QM/33/010/22
10
QM/33/010/23
40
QM/33/440/22
40
QM/33/440/22
12
QM/33/012/22
12
QM/33/012/22
12
QM/33/016/23
50
QM/33/450/22
50
QM/33/450/22
16
QM/33/016/22
16
QM/33/016/22
16
QM/33/016/23
63
QM/33/463/22
63
QM/33/463/22
20
QM/33/020/22
20
QM/33/020/22
20
QM/33/020/23
80
QM/33/480/22
80
QM/33/080/22
25
QM/33/025/22
25
QM/33/025/22
25
QM/33/025/23
100
QM/33/410/22
100
QM/33/100/22
32
QM/33/032/22
125
QM/33/125/22
40
QM/33/040/22
50
QM/33/050/22
63
QM/33/063/22
Dimensions see relevant cylinder sheets.
d.c.
