MSI Keeper 945GME V2.0 User Manual
Page 22
M S-9641 M ainboard
2-10
Link Indicator
Activity Indicator
LED
Color
LED State
Condition
Off
LAN link is not established.
Left
Orange
On (steady state)
LAN link is established.
On (blinking)
The computer is communicating with another computer on the LAN.
Green
Off
10 Mbit/sec data rate is selected.
Right
On
100 Mbit/sec data rate is selected.
Orange
On
1000 Mbit/sec data rate is selected.
LAN (RJ-45) Jack
The standard RJ-45 jack is for connection to single Local Area Network (LAN). You
can connect a network cable to it.
