Manboard Setup

▍

MS-9297

3-3

Manboard Setup

▍

MS-9297

CPU (Central Processing Unit) ��3-4

Introducton to LGA 1366 CPU ...................................................................3-4
CPU Installaton .........................................................................................3-5

Memory ��3-7

Memory Populaton Rules ..........................................................................3-7
Installng Memory Modules ........................................................................3-9

Rear Panel I/O ��3-10
Connector ��3-11

Seral ATA II Connector: SATA1, SATA2 ................................................... 3-11
Seral Attached SCSI Connector: MINISAS1 ........................................... 3-11
IPMB Connector: JIPMB1 ........................................................................3-12
Seral Port Connector: COM1 ..................................................................3-12
Front USB Connector: JUSB1, JUSB3, JUSB4, JUSB5 ..........................3-13

Jumper��3-14

Clear CMOS Jumper: JCLR_CMOS1 ......................................................3-14
BIOS Recovery Jumper: JRECOVERY1 .................................................3-14
BIOS Password Jumper: JPASSWORD1 ................................................3-15
RAID Select Jumper: JRAID_SEL1 .........................................................3-15

Slot ��3-16

PCI (Perpheral Component Interconnect) Express Slot ..........................3-16
