MSI MS-9297 User Manual
Page 12
1-2
Overvew
▍
MS-9297
Overvew
▍
MS-9297
S
yStem
O
verview
Top View
NOTE: Before removng the rear cover, make sure that you remove the ODD
front bezel first to avoid collision and damage.
HDD bay
Slim DVD Drive
Axial Fan Module (redundant)
Fan Duct
PCI Riser Card bracket
SSI EPS 1U Power Supply
1�
2�
3�
4�
5�
6�
1
2
3
4
5
6
