System Assembly
▍
MS-9297
2-15
System Assembly
▍
MS-9297
S
yStem
m
OuntinG
Rack Rails
Important
Only the service personnel can slide out the rack rails.
The chassis rails are designed with locking tabs which can (1) hold the system
firmly to the rack, and (2) lock the system halfway without directly sliding out of
the rack when dismounting.
Step 1. The chasss rals and rack rals have been assembled together be-
forehand. The first thing to do with the rail set is to take the chassis
rals off the rack rals.
Step 2. Press the lockng swtch and pull the chasss ral gently out untl the
lockng tab locks the ral.

•
•
