System Assembly

▍

MS-9297

2-17

System Assembly

▍

MS-9297

Rack Mounting

Step 1. Adjust the rack ral length to

fit your rack.

Step 2. Poston the rack ral at the

desred locaton n the rack.

Make sure the sldng gude

s facng nwards.

Step 3. Secure the rack ral to the

rack wth the cage nuts on

the front and rear brackets.

Step 4. Follow the above procedures

to nstall the second rack

ral.

Step 5. Algn the chasss rals wth

the rack rals. Slde the sys-

tem nto the rack wth even

force on both sdes

Step 6. When the system s locked

halfway, depress the lock-

ng tabs to enable smooth

mountng.

Step 7. The lockng tabs should clck

when the system has been

pushed completely nto the

rack.


