2-2
MS-91C2 Server Board
Quick Components Guide
FAN1, p.2-11
JUSB1~2, p.2-12
J_IPMB1, p.2-13
COM2, p.2-11
SATA1~4, p.2-10
J_SMLINK1, p.2-14
CPU, p.2-3
DIMM Slots,
p.2-7
JBAT1, p.2-15
Back Panel
I/O, p.2-9
JPWR1, p.2-8
J_SMBUS1, p.2-14
JPWR2, p.2-8
JFP1, p.2-13
FAN2, p.2-11 FAN3, p.2-11
CPU, p.2-3
JPWR3, p.2-8
DIMM Slots, p.2-7
PCIE_SLOT1, p.2-16
FAN4, p.2-11
J_BMC_WP1, p.2-15
