HOW TO USE WOOD CHIP LOADER
CAUTION
When door is opened a flare up may occur. Should wood chips flare up, immediately close
door, wait for wood chips to burn down then open door again. Do not spray with water.
9
How to use wood chip loader:
• Before starting unit, place ½ cup of wood chips
in chip loader.
• Never use more than ½ cup of wood chips at a
time. Never use wood chunks.
• Insert wood chip loader into smoker. Wood
chips should be level with top rim of wood chip
loader.
• Turn handle clockwise in direction of arrow
mark on smoker to unload wood. Wood will
drop into wood chip tray. Turn handle counter-
clockwise, to the upright position, and leave
wood chip loader in place.
• Check wood chip tray periodically to see if
wood has burned down by removing wood chip
loader and looking into smoker through hole.
Add more chips as needed.
• Wood chip loader must be pulled out complete-
ly from smoker when checking wood chip level.
Adding more wood during smoking
process:
• Pull wood chip loader from smoker.
• Place wood chips in wood chip loader and
insert into smoker.
• Turn handle clockwise in direction of arrow
mark on smoker to unload wood. Wood will
drop into wood chip tray.
• Temperature may spike briefly after wood is
added. It will stabilize after a short time. Do not
adjust temperature setting.
Caution:
• Keep smoker door closed when adding wood
chips.
• Wood chip loader will be HOT even if handle is
not.
INSTRUCCIONES DE ENSAMBLAJE continuación
Paso 3
Monte el panel de control al insertar
la cabeza del tornillo estabilizador en
la ranura, como se muestra.
Nota: Es probable que el tornillo
estabilizador necesite ajustarse
ligeramente para que quede a la
perfección.
Paso 4
Asegure el panel del control en el
ahumador con los dos (2) tornillos de
cabeza plana m5X.08x10 incluidos.
Nota: No apriete en exceso.
tornillo estabilizador
ranura
