78
HDD
Mode
HDD
Total
Capacity
Remark
A B
Normal 2TB 2TB 4TB
2 separate HDDs are
shown in the system.
2TB is the maximum in
each HDD bay.
RAID 0 1TB 1TB 2TB
2 HDDs are combined as
a single HDD (Stripping).
The maximun capacity
can not exceed 2TB.
RAID 1 2TB 2TB 2TB
2 HDDs are exact
duplicates of each other
(Mirroring).
7.
Native Server/Service and Extension Server/Module
DISKMASTER is equipped with two kinds of service, “Native” and “Extension”.
-
Native Server: “System Management”, “SAMBA server”
and “FTP server”. These functions are DISKMASTER’S
basic services.
-
Extension Server/Modue: “Web servr”, “Database
server”,“UPnP server”,”iTune server”,”Download service”
and “DDNS service”. These are installed modules which
are installed by the user’s demand.
8. Easy NAS Positioning Utility – NASLink
-
NASLink is a Windows based utility, and works with XP, Win-7(32/64).
-
NASLink helps search for DISKMASTER’s LAN IP Address when you
don’t know it.
-
NASLink can help you connect to the web management page easily.
9. HDD Configurations of DISKMASTER
Before DISKMASTER gets working, DISKMASTER has to create a system disk.
HDDs must be formated via DISKMASTER and the HDDs will be partitioned
into 4 partitions as:
/fsys
15 GB Home Directory(/data)
*The remaining capacity of
the HDD
Reserved area
50 MB Swap
1 GB
