SWITCHING CHARACTERISTICS
Notes: 7. Device parameters are specified with a 4.096 MHz clock. If a crystal is used, then XIN frequency must
remain between 2.5 MHz - 5.0 MHz.
8. If external MCLK is used, then its duty cycle must be between 45% and 55% to maintain this spec.
9. Specified using 10% and 90% points on wave-form of interest. Output loaded with 50 pF.
10. Oscillator start-up time varies with crystal parameters. This specification does not apply when using an
external clock source.
Parameter Symbol Min Typ Max Unit
Master Clock Frequency Internal Gate Oscillator (Note 7) MCLK 2.5 4.096 5 MHz
Master Clock Duty Cycle 40 - 60 %
CPUCLK Duty Cycle (Note 8) 40 60 %
Rise Times Any Digital Input Except SCLK
(Note 9) SCLK
Any Digital Output
t
rise
-
-
- -
-
50
1.0
100
-
µs
µs
ns
Fall Times Any Digital Input Except SCLK
(Note 9) SCLK
Any Digital Output
t
fall
-
-
- -
-
50
1.0
100
-
µs
µs
ns
Start-up
Oscillator Start-Up Time XTAL = 4.096 MHz (Note 10) t
ost
- 60 - ms
Serial Port Timing
Serial Clock Frequency SCLK - - 2 MHz
Serial Clock Pulse Width High
Pulse Width Low
t
1
t
2
200
200 -
- -
- ns
ns
SDI Timing
CS Falling to SCLK Rising t
3
50 - - ns
Data Set-up Time Prior to SCLK Rising t
4
50 - - ns
Data Hold Time After SCLK Rising t
5
100 - - ns
SCLK Falling Prior to CS Disable t
6
100 - - ns
SDO Timing
CS Falling to SDI Driving t
7
- 20 50 ns
SCLK Falling to New Data Bit (hold time) t
8
- 20 50 ns
CS Rising to SDO Hi-Z t
9
- 20 50 ns
