Cirrus Logic CDB5532U User Manual
Features, General description, Usb communication with pc

Copyright
© Cirrus Logic, Inc. 2007
(All Rights Reserved)
AIN1+
AIN1-
AIN2+
AIN2-
CRYSTAL
4.9152 MHz
CS5532
A1
A0
SCLK
SDO
SDI
CS
C8051F320
Microcontroller
RESET
CIRCUITRY
Interface Header
AIN1+
AIN1-
AIN2+
AIN2-
VREF-
VREF+
VREF
Source
Select
LT1019
VREF+
VREF-
VD+
VA-
VA+
GND
+5 V
USB
CONNECTOR
CDB5532U
CDB5532U Evaluation Board and Software
Features
USB Communication with PC
On-board Microcontroller
On-board Voltage Reference
Evaluation Software
– Register Setup & Chip Control
– FFT Analysis
– Time Domain Analysis
– Noise Histogram Analysis
Interface Header for External Microcontroller
General Description
The CDB5532U is an inexpensive tool designed to eval-
uate the functionality and performance of the CS5532.
The CS5532 datasheet should be read and consulted
when using the CDB5532U evaluation board.
The evaluation board includes a C8051F320 microcon-
troller with a USB interface. The microcontroller controls
the serial communication between the evaluation board
and the PC via the firmware, enabling quick and easy ac-
cess to all of the CS5532’s registers and functions.
The CDB5532U includes software for data capture, time
domain analysis, histogram analysis, and frequency do-
main analysis.
ORDERING INFORMATION
CDB5532U
Evaluation Board
AUG ‘07
DS807DB1
Document Outline
- Features & Description
- Table of Contents
- 1. Hardware
- 2. Software
- 3. Schematics
- 4. Board Layout
- Revision History
