CDB5521/22/23/24/28

DS317DB2

9

1.6 Software

The evaluation board comes with software and an
RS-232 cable to link the evaluation board to the
PC. The executable software was developed with
Lab Windows/CVI

TM

and meant to run under Win-

dows

TM

3.1 or later. After installing the software,

read the readme.txt file for last minute changes in
the software. Additionally, Section 2., Part II: Soft-
ware
further details how to install and use the soft-
ware

1.7. Writing Your Own Interface Software

Tables 2 through 5 list the RS-232 commands used
to communicate between the PC and the microcon-
troller. To develop additional code to communi-
cate to the evaluation board via RS-232, the
following applies: to write to an internal ADC reg-
ister, choose the appropriate write command byte
(See Table 2), and transmit it LSB first. Then,
transmit the three data bytes lowest order byte (bits
7-0) first with the LSB of each byte transmitted
first. These three data bytes provide the 24-bits of
information to be written to the desired register.
To read from an internal register, choose the appro-
priate read command byte and transmit it LSB first.
Then, the microcontroller automatically acquires the
ADC’s register contents and returns the 24-bits of
information. The returned data is transmitted lowest
order byte first with the LSB of each byte transmit-
ted first.

Name

Function Description

HDR1

Used to switch AIN1+ (AIN1 on
CS5528) between J1 and AGND.

HDR2

Used to switch AIN1- (AIN2 on
CS5528) between J1 and AGND.

HDR3

Does not exist.

HDR4

Used to switch the power for NBV
from the LM337, CPD, or AGND.

HDR5

Used to switch VREF+ and VREF-
pins from external J2 header to the on
board LT1019 reference.

HDR6

Used to connect an external micro-
controller.

HDR7

Used in conjunction with the self test
modes to test the UART/RS232 com-
munication link between the micro-
controller and a PC.

HDR8

Used to switch AIN2 + (AIN3 on
CS5528) between J1 and AGND.

HDR9

Used to switch AIN2- (AIN4 on
CS5528) between J1 and AGND.

HDR10

Does not exist.

HDR11

Used to switch AIN3+ (AIN5 on
CS5528) between J1 and AGND.

HDR12

Used to switch AIN3- (AIN6 on
CS5528) between J1 and AGND.

HDR13

Used to switch AIN4+ (AIN7 on
CS5528) between J1 and AGND.

HDR14

Used to switch AIN4- (AIN8 on
CS5528) between J1 and AGND.

Table 1. Header Descriptions
