Self-Offset Calibration Calibration Command (HEX)
Self-Offset Calibration on Setup 1 81
Self-Offset Calibration on Setup 2 89
Self-Offset Calibration on Setup 3 91
Self-Offset Calibration on Setup 4 99
Self-Offset Calibration on Setup 5 A1
Self-Offset Calibration on Setup 6 A9
Self-Offset Calibration on Setup 7 B1
Self-Offset Calibration on Setup 8 B9
Self-Offset Calibration on Setup 9 C1
Self-Offset Calibration on Setup 10 C9
Self-Offset Calibration on Setup 11 D1
Self-Offset Calibration on Setup 12 D9
Self-Offset Calibration on Setup 13 E1
Self-Offset Calibration on Setup 14 E9
Self-Offset Calibration on Setup 15 F1
Self-Offset Calibration on Setup 16 F9
Self Gain Calibration Calibration Command (HEX)
Self-Gain Calibration on Setup 1 82
Self-Gain Calibration on Setup 2 8A
Self-Gain Calibration on Setup 3 92
Self-Gain Calibration on Setup 4 9A
Self-Gain Calibration on Setup 5 A2
Self-Gain Calibration on Setup 6 AA
Self-Gain Calibration on Setup 7 B2
Self-Gain Calibration on Setup 8 BA
Self-Gain Calibration on Setup 9 C2
Self-Gain Calibration on Setup 10 CA
Self-Gain Calibration on Setup 11 D2
Self-Gain Calibration on Setup 12 DA
Self-Gain Calibration on Setup 13 E2
Self-Gain Calibration on Setup 14 EA
Self-Gain Calibration on Setup 15 F2
Self-Gain Calibration on Setup 16 FA
Table 4. Microcontroller Self Calibration Commands via RS-232
