CDB5374
DS862DB1
53
CIRRUS LOGIC
CDB5374-Z_Rev_A.bom
BILL OF MATERIAL (Page 2 of 2)
Item
Cirrus P/N
Rev
Description
Qty
Reference Designator
MFG
MFG P/N
Notes
34
020-00934-Z1
A
RES 200 OHM 1/10W ±1% NPb 0603 FILM
10
R3 R17 R39 R40 R41 R55 R63 R69 R70 R71
DALE
CRCW0603200RFKEA
35
020-01130-Z1
A
RES 10k OHM 1/10W ±1% NPb 0603 FILM
16
R4 R6 R7 R8 R18 R20 R47 R51 R54 R56 R73
R74 R75 R501 R511 R515
DALE
CRCW060310K0FKEA
36
020-01074-Z1
A
RES 3.32k OHM 1/10W ±1% NPb 0603
2
R9 R58
DALE
CRCW06033K32FKEA
37
020-01128-Z1
A
RES 9.53k OHM 1/10W ±1% NPb 0603
3
R10 R12 R21
DALE
CRCW06039K53FKEA
38
020-01104-Z1
A
RES 5.9k OHM 1/10W ±1% NPb 0603 FLM
1
R19
DALE
CRCW06035K90FKEA
39
000-00001-Z1
A
NO POP RES NPb 0805
0
R22 R23 R32 R33 R43 R52 R243 R252 R343
R352 R443 R452
NO POP
NP-RES-0805
DO NOT POPULATE
40
020-06288-Z1
A
RES 680 OHM 1/10W ±1% NPb 0603 FILM
16
R27 R28 R29 R30 R72 R76 R77 R78 R79 R80
R81 R82 R83 R84 R85 R86
DALE
CRCW0603680RFKEA
41
021-01391-Z1
A
RES 18M OHM 1/8W ±5% NPb 0805
8
R31 R38 R231 R238 R331 R338 R431 R438
PANASONIC
ERJ6GEYK186V
42
020-00673-Z1
A
RES 0 OHM 1/10W ±5% NPb 0603 FILM
25
R34 R36 R44 R45 R48 R49 R62 R234 R236
R244 R245 R248 R249 R334 R336 R344 R345
R348 R349 R434 R436 R444 R445 R448 R449
DALE
CRCW06030000ZSEA
43
020-01048-Z1
A
RES 2k OHM 1/10W ±1% NPb 0603 FILM
8
R35 R37 R235 R237 R335 R337 R435 R437
DALE
CRCW06032K00FKEA
44
020-06253-Z1
A
RES 412k OHM 1/4W ±1% NPb 1206
4
R50 R87 R88 R89
DALE
CRCW1206412KFKEA
45
000-00002-Z1
A
NO POP RES NPb 0603
0
R61
NO POP
NP-RES-0603
DO NOT POPULATE
46
020-01016-Z1
A
RES 1k OHM 1/10W ±1% NPb 0603 FILM
4
R64 R65 R66 R67
DALE
CRCW06031K00FKEA
47
120-00002-Z1
A
SWT SPST 130G 0/1 5mm TACT ESD NPb
3
S2 S3 S4
C&K
PTS645TL50
INSTALL AFTER WASH PROCESS
48
120-00011-Z1
A
SWT 4 POS DIP RAISED NPb SPST
1
S
5
GRAYHILL
76SB04T
INSTALL AFTER WASH PROCESS
49
060-00195-Z1
A
IC LOW V DUL SPST ANA SW NPb MSP8
2
U1 U2
VISHAY
DG2003DQ-T1-E3
ALTERNATE is DG2037DQ-T1-E3
50
060-00063-Z1
A
IC LNR V REG 200mA ADJ NPb SOT23-5
1
U
3
LINEAR TECH
LT1964ES5-BYP#PBF
51
061-00062-Z1
A
IC LOG SGL D-FF CLR PREST NPb SSOP8
5
U4 U9 U10 U15 U16
TEXAS INSTRUMENTS
SN74LVC2G74DCTRE4
52
060-00062-Z1
A
IC LN V REG LNOIS 500mA NPb SO8-150
4
U5 U6 U7 U8
LINEAR TECH
LT1763CS8#PBF
53
065-00178-Z1
E
IC CRUS LOW V AMP DC-1kHz NPb SOIC8
1
U11
CIRRUS LOGIC
CS3011-ISZ/E
54
060-00162-Z1
A
IC 3.3V U LW PWR RS485 XCVR NPSOIC8
4
U12 U13 U17 U18
LINEAR TECH
LTC1480IS8#PBF
55
060-00236-Z1
A
IC LNR PRC VRF 2.5V TC10 NPbSO8-150
1
U14
LINEAR TECH
LT1019AIS8-2.5#PBF
ALTERNATE is LT1019IS8-2.5#PBF
56
065-00287-Z1
A0
IC CRUS DL HIPER AMP MOD NPb QFN48
2
U19 U21
CIRRUS LOGIC
CS5374-INZ/A0
57
065-00173-Z1
D
IC CRUS TEST DAC SSOP28 NPb
1
U20
CIRRUS LOGIC
CS4373A-ISZ/D
58
065-00056-Z1
A
IC CRUS LPWR MCH FLTR NPb TQFP64
1
U22
CIRRUS LOGIC
CS5376A-IQZ/A
59
060-00067-Z1
A
IC LNR DL CMOS SW DBNCR NPb SOT23-6
2
U23 U26
MAXIM
MAX6817EUT+T
60
061-00064-Z1
A
IC LOG, HEX INVERTER NPb SO14-150
1
U24
TEXAS INSTRUMENTS
SN74LVC04ADE4
61
062-00022-Z1
A
IC PGM EEPROM 8kX8 SPISER NPb SOIC8
1
U25
ATMEL
AT25640AN-10SU-2.7
62
062-00055-Z1
A
IC PGM 128 MCROCLL CPLD NPb VQFP100
1
U27
XILINX
XCR3128XL-10VQG100I
63
062-00079-Z1
A
IC PGM USB 16kB FLAS MCU NPb LQFP32
1
U28
SILICON
LABORATORIES INC
C8051F320-GQ
PROGRAM AT TEST
64
061-00061-Z1
A
IC LOG 2IN XOR NPb SOT23-5
1
U505
TEXAS INSTRUMENTS
SN74LVC1G86DBVR
65
060-00175-Z1
A
IC 1.25MHz R2R OPAMP NPb SOT23-5
1
U507
LINEAR TECH
LT1783IS5#TRMPBF
66
080-00003-Z1
A
WIRE BPOST 1.5X.25 24/19 GA BLU NPb
4
XJ6 XJ7 XJ8 XJ9
SQUIRES
L-1.5X.25TX.25T_TYPE_E_
WIRES FOR BINDING POSTS
67
300-00025-Z1
A
SCREW 4-40X5/16" PH MACH SS NPb
8
XMH1 XMH2 XMH3 XMH4 XMH5 XMH6 XMH7
XMH8
BUILDING FASTENERS
PMSSS 440 0031 PH
SCREWS FOR STANDOFFS
68
102-00017-Z1
A
OSC 32.768MHz 50ppm 3.3V VCL NPb SM
1
Y
1
CITIZEN
CSX750VKB32.768M-UT
69
070-00005-Z1
A
DIODE TR 13V 600W NPb AXL
3
Z1 Z2 Z3
LITTLE FUSE
P6KE13A
70
240-00355-Z1
A
PCB CDB5374
1
CIRRUS LOGIC
240-00355-Z1
71
603-00355-Z1
A
ASSY DWG CDB5374
REF
CIRRUS LOGIC
603-00355-Z1
72
600-00355-Z1
A
SCHEM CDB5374
REF
CIRRUS LOGIC
600-00355-Z1
73
115-00003-Z1
A
HDR 5x2 ML .1"CTR S GLD NPb
0
J31 J40 J503 J525 J526
SAMTEC
TSW-105-07-G-D
DO NOT POPULATE
74
115-00029-Z1
A
HDR 8x2 ML .1" 062BD ST GLD NPB TH
0
J38 J48 J49 J51
SAMTEC
TSW-108-07-G-D
DO NOT POPULATE
75
115-00011-Z1
A
HDR 10x2 ML .1" 062BD ST GLD NPb TH
0
J44 J46 J52 J53 J54 J55 J61 J62
SAMTEC
TSW-110-07-G-D
DO NOT POPULATE
76
115-00012-Z1
A
HDR 4x2 ML .1"CTR S GLD NPb
0
J45
SAMTEC
TSW-104-07-G-D
DO NOT POPULATE
77
115-00013-Z1
A
HDR 2x2 ML .1"CTR .062BD S GLD NPb
0
J57
SAMTEC
TSW-102-07-G-D
DO NOT POPULATE
78
115-00030-Z1
A
HDR 6x2 ML .1"CTR 062 S GLD NPb
0
J502 J541 J545
SAMTEC
TSW-106-07-G-D
DO NOT POPULATE
