2.2.4 Delta-Sigma Test DAC
The CS4373A DAC creates differential analog signals for system tests. Multiple test modes are available
and their use is described in the CS4373A data sheet.
2.2.4.1 Precision Output - DAC_OUT
The CS4373A test DAC has a precision output (DAC_OUT) that is routed to the input selection jumpers
for each channel. This output is sensitive to loading, and on CDB5374 should only be jumper-ed into the
INB inputs which do not have passive RC filter components installed. The input impedance of the INB am-
plifier inputs are high enough that the precision output can be directly connected to the INB inputs of all
channels simultaneously.
2.2.4.2 Buffered Output - DAC_BUF
The CS4373A test DAC has a buffered output (DAC_BUF) that is routed to the input selection jumpers
for each channel. This output is less sensitive to loading than the precision outputs, and can be jumper-
ed into either the INA or INB inputs without affecting performance. The buffered output can also drive a
sensor attached to the input screw terminals, provided the sensor meets the impedance requirements
specified in the CS4373A data sheet.
Analog Signals Description
OUT Precision differential analog output
BUF Buffered differential analog output
CAP Capacitor connection for internal anti-alias filter
VREF Voltage reference analog inputs
Digital Signals
Description
TDATA Delta-sigma test data input
MCLK Clock input
SYNC Synchronization input
MODE[0..2] Test mode selection
ATT[0..2] Attenuation range selection
