Switch# 0=Closed, 1=Open Comment
3 PRO=0 Consumer Mode C0=0
1,4 FC1, FC0 C24,C25,C26,C27 - Sample Frequency
0 0
*0 1
1 0
1 1
0000 - 44.1 kHz
0100 - 48 kHz
1100 - 32 kHz
0000 - 44.1 kHz, CD Mode
2 C3 C3,C4,C5 - Emphasis (1 of 3 bits)
*1
0
000 - None
100 - 50/15
µ
s
5 C2 C2 - Copy/Copyright
1
*0
0 - Copy Inhibited/Copyright Asserted
1 - Copy Permitted/Copyright Not Asserted
6 C15 C15 - Generation Status
1
*0
0 - Definition is based on category code.
1 - See CS8402A Data Sheet, App. A
8,7 C8, C9 C8-C14 - Category Code (2 of 7 bits)
1 1
1 0
0 1
*0 0
0000000 - General
0100000 - PCM encoder/decoder
1000000 - Compact Disk - CD
1100000 - Digital Audio Tape - DAT
* Default setting from factory
Table 4. CS8402A Switch Definitions - Consumer Mode
Switch# 0=Closed, 1=Open Comment
3 PRO=0 Professional Mode C0=1(default)
1 CRE Local Sample Address Counter & Reliability Flags
default
0
1 Disabled
Internally Generated
2,5 C6, C7 C6,C7 - Sample Frequency
default
1 1
1 0
0 1
0 0 00 - Not Indicated - Default to 48 kHz
01 - 48 kHz
10 - 44.1 kHz
11 - 32 kHz
4 C1 C1 - Audio
default
1
0 0 - Normal Audio
1 - Non-Audio
6 C9 C8,C9,C10,C11 - Channel Mode (1 of 4 bits)
default
1
0 0000 - Not indicated - Default to 2-channel
0100 - Stereophonic
8,7 EM1, EM0 C2,C3,C4 - Emphasis (2 of 3 bits)
default
1 1
1 0
0 1
0 0 000 - Not Indicated - default to none
100 - No emphasis
110 - 50/15
µ
s
111 - CCITT J.17
Table 5. CS8402A Switch Definitions - Professional Mode
CDB5330A / CDB5331A
DS138DB2 21
