JUMPER PURPOSE POSITION FUNCTION SELECTED
HDR1
CS5330A/31A SCLK
Selection for CS8402A
*5330A CS5330A Selected
5331A CS5331A Selected
HDR10
Master/Slave Mode
Selection *High MASTER Mode
SLAVE Mode
Low
HDR9
Selects source of system
clocks *High MASTER Mode (5330A Clocks)
Low SLAVE Mode (External Clocks)
HDR22
HDR23
Clock I/O
*0
*1 See Input/Output for Clocks and Data
section of text
HDR6
Selects 256
×
or
512
×
MCLK for CS8402A
*256
512
See CS8402A data sheet for details
HDR5 (M2)
CS8402A mode select
*Low See CS8402A data sheet
for details HDR4 (M1) *Low
HDR3 (M0) *High
* Default setting from factory
Table 2. CDB5330A Jumper Selectable Options
JUMPER PURPOSE POSITION FUNCTION SELECTED
HDR1
CS5330A/31A SCLK
Selection for CS8402A
5330A CS5330A Selected
*5331A CS5331A Selected
HDR10
Master/Slave Mode
Selection *High MASTER Mode
SLAVE Mode
Low
HDR9
Selects source of system
clocks *High MASTER Mode (5331A Clocks)
Low SLAVE Mode (External Clocks)
HDR22
HDR23
Clock I/O
*0
*1 See Input/Output for Clocks and Data
section of text
HDR6
Selects 256
×
or
512
×
MCLK for CS8402A
*256
512
See CS8402A data sheet for details
HDR5 (M2)
CS8402A mode select
*High See CS8402A data sheet
for details
HDR4 (M1) *Low
HDR3 (M0) *Low
* Default setting from factory
Table 3. CDB5331A Jumper Selectable Options
CDB5330A / CDB5331A
20 DS138DB2
