1.
CHARACTERISTICS AND SPECIFICATIONS
•
Min / Max characteristics and specifications are guaranteed over the
Specified Operating Conditions
.
•
Typical performance characteristics and specifications are measured at nominal supply voltages and T
A
= 25
°C.
•
GND = 0 V. Single-ended voltages with respect to GND, differential voltages with respect to opposite half.
•
Device is connected as shown in
unless otherwise noted.
SPECIFIED OPERATING CONDITIONS
Notes: 1. VA- must always be the most-negative input voltage to avoid potential SCR latch-up conditions.
2. By design, a 2.500 V voltage reference input results in the best signal-to-noise performance.
3. Full-scale accuracy is directly proportional to the voltage reference absolute accuracy.
4. VREF inputs must satisfy: VA- < VREF- < VREF+ < VA+.
Parameter
Symbol Min Nom
Max
Unit
Bipolar Power Supplies
Positive Analog
±
2%
VA+
2.45
2.50
2.55
V
Negative Analog
)
±
2%
VA-
-2.45
-2.50
-2.55
V
Positive Digital
±
3%
VD
3.20
3.30
3.40
V
Voltage Reference Input
{VREF+} - {VREF-}
)
VREF
-
2.500
-
V
VREF-
)
VREF-
-
VA -
-
V
Thermal
Ambient Operating Temperature
Industrial (-IS, -ISZ)
T
A
-40
25
85
°C
Modes of Operation
Selection
MODE[2:0]
Mode Description
0
0 0 0
Sleep mode.
1
0 0 1
AC OUT and BUF outputs.
2
0 1 0
AC OUT only, BUF high-z.
3
0 1 1
AC BUF only, OUT high-z.
4
1 0 0
DC common mode output.
5
1 0 1
DC differential output.
6
1 1 0
AC common mode output.
7
1 1 1
Sleep mode.
Attenuation
Selection
ATT[2:0]
Attenuation
dB
0
0 0 0
1/1
0 dB
1
0 0 1
1/2
-6.02 dB
2
0 1 0
1/4
-12.04 dB
3
0 1 1
1/8
-18.06 dB
4
1 0 0
1/16
-24.08 dB
5
1 0 1
1/32
-30.10 dB
6
1 1 0
1/64
-36.12 dB
7
1 1 1
reserved
reserved
Table 1. Selections for Operational Mode and Attenuation
