CS4373A
DS699F2 13
DIGITAL CHARACTERISTICS (CONT.)
Notes: 25. MCLK is generated by the CS5376A digital filter. If MCLK is disabled, the device automatically enters
a power-down state.
26. MSYNC is generated by the CS5376A digital filter and is latched on MCLK rising edge, synchronization
instant (t
0
) on next MCLK rising edge.
27. TDATA can be delayed from 0 to 63 full bit periods by the CS5376A test bit stream generator. The timing
diagram shows no TBSDATA delay.
Parameter Symbol Min Typ Max Unit
Master Clock
MCLK Frequency ( Note 25 ) f
CLK
- 2.048 - MHz
MCLK Period ( Note 25 ) t
mclk
- 488 - ns
MCLK Duty Cycle ( Note 8 ) MCLK
DC
40 - 60 %
MCLK Rise Time ( Note 8 ) t
RISE
- - 50 ns
MCLK Fall Time ( Note 8 ) t
FALL
- - 50 ns
MCLK Jitter (In-band or aliased in-band) ( Note 8 ) MCLK
IBJ
- - 300 ps
MCLK Jitter (Out-of-band) ( Note 8 ) MCLK
OBJ
- - 1 ns
Master Sync
MSYNC Setup Time to MCLK rising ( Note 8, 26 ) t
mss
20 122 - ns
MSYNC Period ( Note 8, 26 ) t
msync
40 976 - ns
MSYNC Hold Time after MCLK falling ( Note 8, 26 ) t
msh
20 122 - ns
MSYNC Instant to TDATA Start ( Note 8, 27 ) t
tdata
- 1220 - ns
