CS43122

18

AD1/CDIN

(Control Port Mode)

3

Address Bit 1 / Control Data Input

(Input) - In 2 Wire Mode, AD1 is a chip

address bit. CDIN is the control data input line for the control port interface in SPI
mode.

SCL/CCLK

(Control Port Mode)

4

Serial Control Interface Clock

(Input) - In 2 Wire Mode, SCL clocks the serial

control data into or from SDA/CDOUT.
In SPI mode, CCLK clocks the serial data into AD1/CDIN and out of SDA/CDOUT.

SDA/CDOUT

(Control Port Mode)

5

Serial Control Data I/O

(Input/Output) - In 2 Wire Mode, SDA is a data input/out-

put. CDOUT is the control data output for the control port interface in SPI mode.

M1

(Control Port Mode)

14

Mode Select

(Input) - This pin is not used in Control Port Mode and must be termi-

nated to ground.
