CDB4265

12

DS657DB1

5. FPGA REGISTER DESCRIPTION

5.1

CODE REVISION ID - REGISTER 01H

Function:

Identifies the revision of the FPGA code. This register is Read-Only.

5.2

MCLK SOURCE CONTROL - ADDRESS 02H

5.2.1

MCLK SOURCE (BITS 5:4)

Default = 10
Function:

These bits select the source of the CS4265 MCLK signal. Table 1 shows the available settings.

7

6

5

4

3

2

1

0

Rev7

Rev6

Rev5

Rev4

Rev3

Rev2

Rev1

Rev0

7

6

5

4

3

2

1

0

Reserved

Reserved

MCLK1

MCLK0

Reserved

Reserved

Reserved

Reserved

Table 1. MCLK Source

MCLK1

MCLK0

MCLK Source

0

0

Oscillator

0

1

MCLK position on PCM Header (J15)

1

0

CS8416 RMCK

1

1

Reserved
