Page 25: Cs4228a
CS4228A
25
5.9
Serial Port Mode
Address 0x0D
DCK1:0
Sets the number of Serial Clocks (SCLK) per Fs period (LRCLK)
DMS1:0
Sets the master/slave mode of the serial audio port
*0 -
Slave (External LRCLK, SCLK)
1 -
Reserved
2 -
Reserved
3 -
Master (No 48 Fs SCLK in BRM)
DDF2:0
Serial Port Data Format
0 -
Right Justified, 24-bit
1 -
Right Justified, 20-bit
2 -
Right Justified, 16-bit
3 -
Left Justified, maximum 24-bit
*4 -
I
2
S compatible, maximum 24-bit
5 -
One-line Data Mode, available in BRM only
6 -
Reserved
7 -
Reserved
5.10
Chip Status
Address 0x0E
CLKERR
Clocking system status, read only
0 -
No Error
1 -
No MCLK is present, or a request for clock change is in progress
ADCOVL
ADC overflow bit, read only
0 -
No overflow
1 -
ADC overflow has occurred
7
6
5
4
3
2
1
0
DCK1
DCK0
DMS1
DMS0
RESERVED
DDF2
DDF1
DFF0
1
0
0
0
0
1
0
0
DCK1:0
BRM (Fs)
HRM (Fs)
0
32 (1)
(3)
1
48 (2)
(3)
2
*64
32 (1)
3
128
64
Notes: 1. All formats will default to 16 bits
2. Slave mode only
3. Invalid mode
7
6
5
4
3
2
1
0
CLKERR
ADCOVL
RESERVED
X
X
0
0
0
0
0
0
