1.2.1 Default Jumper Settings
J27, J227, J327, J427
CH1, CH2, CH3, CH4
Analog Input Selections
DAC_OUT+ 1 * * 2 INA+
DAC_OUT- 3 * * 4 INA-
DAC_OUT- 5 ---------- 6 INB-
DAC_OUT+ 7 ---------- 8 INB+
DAC_BUF+ 9 ---------- 10 INA+
DAC_BUF- 11 ---------- 12 INA-
DAC_BUF- 13 * * 14 INB-
DAC_BUF+ 15 * * 16 INB+
BNC_IN+ 17 * * 18 INA+
BNC_IN- 19 * * 20 INA-
BNC_IN- 21 * * 22 INB-
BNC_IN+ 23 * * 24 INB+
Table 1. Analog Inputs Default Jumper Settings
Table 2. VREF, SPI, SYNC, RESET Default Jumper Settings
J519, J19, J20
Voltage Reference Jumpers
VREF+ 1 ---------- 2
VREF- 3 ---------- 4
J43
SPI Chip Select Input
SSI 1 ---------- 2 SSI
EECS 3 * * 4 SSI
J56
SYNC Source Selection
SYNC_IO 1 ---------- 2 SYNC
J58
RESET Source Selection
RST_PB 1 ---------- 2
RST_EXT 3 * * 4
