CDB5376
DS612DB3 55
4. BILL OF MATERIALS
CIRRUS LOGIC CDB5376_REV_D2.bom
BILL OF MATERIAL (Page 1 of 3)
Item
Cirrus P/N
Rev
Description
Qty
Reference Designator
MFG
MFG P/N
Notes
1
001-04345-01
A
CAP 0.1uF ±10% 50V X7R 0805
69
C1 C2 C11 C12 C13 C15 C16 C17 C24 C25 C26 C27 C30 C31 C32 C33 C34 C36 C42 C43 C44 C45 C48 C49 C51 C52 C54 C55 C57 C60 C61 C62 C63 C64 C65 C66 C67 C68 C69 C70 C71 C72 C73 C74 C75 C76 C77 C78 C79 C80 C81 C261 C262 C268 C361 C362 C368 C461 C462 C468 C506 C509 C513 C516 C542 C543 C563 C564 C569
KEMET
C0805C104K5RAC
2
001-04076-01
A
CAP 0.01uF ±10% 50V X7R 0805
8
C3 C4 C5 C9 C10 C14 C22 C23
KEMET
C0805C103K5RAC
3
004-00102-01
A
CAP 100uF ±10% 16V TANT CASE D
1
1
C6 C7 C8 C18 C19 C20 C21 C28 C29 C35 C520
KEMET
T491D107K016AS
4
001-06603-01
A
CAP 0.01uF ±5% 25V C0G 1206
25
C37 C38 C39 C40 C41 C46 C47 C50 C237 C238 C239 C240 C246 C247 C250 C337 C338 C339 C340 C437 C438 C439 C440 C507 C510
KEMET
C1206C103J3GAC
ECO546
5
000-00000-09
A
NO POP CAP 1206
0
C53 C56 C58 C253 C256 C258 C346 C350 C353 C356 C358 C446 C450 C453 C456 C458
NO POP
NP-CAP-1206
DO NOT POPULATE
6
004-00068-01
A
CAP 4.7uF ±10% 10V TANT CASE A
1
C59
KEMET
T491A475K010AS
7
070-00004-01
A
DIODE SCHOTTKY BARRIER 30V 0.2A AXL
4
D1 D2 D3 D4
PHILIPS
BAT85
8
070-00024-01
A
DIODE SWT 70V 215mA SOT-23
16
D5 D6 D7 D8 D205 D206 D207 D208 D305 D306 D307 D308 D405 D406 D407 D408
ON SEMI
BAV99LT1
9
070-00055-01
A
DIODE ARRAY 5V (TVS) ESD SOT143
1
D
9
LITTLE FUSE
SP0503BAHT
10
165-00004-01
A
LED CLR SUP RED 1.7V 1mA 1.6MCD SMD
1
D10
CHICAGO MINIATURE
CMD28-21SRC/TR8/T1
11
110-00028-01
A
CON BNC-PCB RCPT RA
1
J
4
POMONA
MODEL 4788
12
130-00007-01
A
JACK BAN SOLDER TERM, NYLON INS GRN
1
J
6
JOHNSON COMPONENTS
108-0904-001
REQUIRES BINDING POST HOOK UP WIRE. L 1.500 X 0.250T X 0.250T TYPE E 24/19 BLU SQUIRES ELEC. INC.
13
130-00009-01
A
JACK BAN SOLDER TERM, NYLON INS YLW
1
J
7
JOHNSON COMPONENTS
108-0907-001
REQUIRES BINDING POST HOOK UP WIRE. L 1.500 X 0.250T X 0.250T TYPE E 24/19 BLU SQUIRES ELEC. INC.
14
130-00014-01
A
JACK BAN SOLDER TERM NYLON INS BLK
1
J
8
JOHNSON COMPONENTS
108-0903-001
REQUIRES BINDING POST HOOK UP WIRE. L 1.500 X 0.250T X 0.250T TYPE E 24/19 BLU SQUIRES ELEC. INC.
15
130-00006-01
A
JACK BAN SOLDER TERM, NYLON INS RED
1
J
9
JOHNSON COMPONENTS
108-0902-001
REQUIRES BINDING POST HOOK UP WIRE. L 1.500 X 0.250T X 0.250T TYPE E 24/19 BLU SQUIRES ELEC. INC.
16
115-00016-01
A
HDR 3x2 MLE .1"CTR S GLD
3
J10 J11 J21
SAMTEC
TSW-103-07-G-D
17
115-00013-01
A
HDR 2x2 MLE .1"CTR S GLD
11
J12 J13 J19 J20 J22 J23 J33 J34 J43 J58 J519
SAMTEC
TSW-102-07-G-D
18
115-00012-01
A
HDR 4x2 MLE .1"CTR S GLD
4
J14 J15 J24 J25
SAMTEC
TSW-104-07-G-D
19
115-00030-01
A
HDR 6x2 MLE .1"CTR S GLD
1
J16
SAMTEC
TSW-106-07-G-D
20
115-00029-01
A
HDR 8x2 ML .1" CTR 062BD ST GLD TH
2
J17 J18
SAMTEC
TSW-108-07-G-D
21
115-00011-01
A
HDR 10x2 ML .1"CTR 062BD ST GLD TH
1
J26
SAMTEC
TSW-110-07-G-D
22
115-00061-01
A
HDR 12x2 MLE .1" CTR D GLD
4
J27 J227 J327 J427
SAMTEC
TSW-112-07-G-D
23
115-00023-01
A
HDR 14x2 MLE .1"CTR S GLD
0
J30 J37
SAMTEC
TSW-114-07-G-D
DO NOT POPULATE
24
110-00055-01
A
CON TERM BLOCK 4 POS 5mm C/C BLUE
8
J32 J41 J232 J241 J332 J341 J432 J441
OST
ED 100/4DS
ASSEMBLE CONNECTORS TOGETHER BEFORE INSTALLATION TO PCB
25
115-00176-01
A
HDR 7x2 ML 2MM CTR 062BD S GLD TH
1
J39
MOLEX
87758-1416
26
110-00041-01
A
CON RA USB BLK
1
J47
AMP
787780-1
27
110-00056-01
A
CON TERM BLOCK 2 POS 5mm C/C BLUE
3
J50 J59 J63
ON-SHORE TECHNOLOGY
ED 100/2DS
28
115-00014-01
A
HDR 2x1 ML .1"CTR 062BD ST GLD TH
1
J56
SAMTEC
TSW-102-07-G-S
