Cirrus Logic CDB5376 - Manual (Page 56)

CDB5376
56 DS612DB3
CIRRUS LOGIC CDB5376_REV_D2.bom
BILL OF MATERIAL (Page 2 of 3)
Item
Cirrus P/N
Rev
Description
Qty
Reference Designator
MFG
MFG P/N
Notes
29
115-00003-01
A
HDR 5x2 MLE .1"CTR S GLD
1
J60
SAMTEC
TSW-105-07-G-D
30
080-00004-01
A
WIRE, JUMPER 2P, 0.1"CTR, BRASS
8
JP1 JP2 JP3 JP4 JP5 JP6 JP7 JP8
COMPONENTS CORPORATION
TP-101-10
31
304-00001-01
A
SPCR, STANDOFF 4-40 THR, 0.875"L
8
MH1 MH2 MH3 MH4 MH5 MH6 MH7 MH8
KEYSTONE
1809
REQUIRES 4-40- PAN HEAD SCREW
32
020-00788-01
A
RES 10 OHM 1/10W ±1% 0603 FILM
13
R1 R5 R11 R13 R14 R15 R16 R24 R25 R26 R68 R514 R519
DALE
CRCW060310R0F
33
020-01244-01
A
RES 100k OHM 1/10W ±1% 0603 FILM
8
R2 R42 R46 R50 R53 R57 R59 R60
DALE
CRCW06031003F
34
020-00934-01
A
RES 200 OHM 1/10W ±1% 0603 FILM
19
R3 R17 R34 R35 R36 R37 R39 R40 R41 R55 R63 R69 R70 R71 R72 R234 R235 R236 R237
DALE
CRCW06032000F
ECO546
35
020-01130-01
A
RES 10k OHM 1/10W ±1% 0603 FILM
16
R4 R6 R7 R8 R18 R20 R47 R51 R54 R56 R73 R74 R75 R501 R511 R515
DALE
CRCW06031002F
36
020-01074-01
A
RES 3.32k OHM 1/10W ±1% 0603 FILM
2
R9 R58
DALE
CRCW06033321F
37
020-01128-01
A
RES 9.53k OHM 1/10W ±1% 0603 FILM
3
R10 R12 R21
DALE
CRCW06039531F
38
020-01104-01
A
RES 5.9k OHM 1/10W ±1% 0603 FILM
1
R19
DALE
CRCW06035901F
39
000-00000-01
A
NO POP RES 0805
0
R22 R23 R32 R33 R43 R52 R243 R252 R343 R352 R443 R452
NO POP
NP-RES-0805
DO NOT POPULATE
40
020-00673-01
A
RES 0 OHM 1/10W ±5% 0603 FILM
21
R44 R45 R48 R49 R62 R244 R245 R248 R249 R334 R336 R344 R345 R348 R349 R434 R436 R444 R445 R448 R449
DALE
CRCW0603000Z
ECO546
41
020-01962-01
A
RES 20k OHM 1/8W ±1% 0805 FILM
4
R31 R38 R231 R238
DALE
CRCW08052002F
42
000-00000-02
A
NO POP RES 0603
0
R61
NO POP
NP-RES-0603
DO NOT POPULATE
43
020-01016-01
A
RES 1k OHM 1/10W ±1% 0603 FILM
4
R64 R65 R66 R67
DALE
CRCW06031001F
44
021-01391-01
A
RES 18M OHM 1/8W ±5% 0805
4
R331 R338 R431 R438
PANASONIC
ERJ6GEYK186V
45
120-00002-01
A
SWITCH 0/1 TACT W/ESD
3
S2 S3 S4
C&K
PTS645TL50
INSTALL AFTER WASH PROCESS
46
120-00011-01
A
SWITCH, 4 POS, DIP, RAISED, SPST
1
S
5
GRAYHILL
76SB04
47
060-00195-01
A
IC LOW V DUAL SPST ANA SWITCH MSOP8
2
U1 U2
VISHAY
DG2003DQ
48
060-00063-01
A
IC LNR, V REG 200mA NEG ADJ SOT23-5
1
U
3
LINEAR TECH
LT1964ES5-BYP
49
061-00062-01
A
IC LOG, LITTLE LOG SNGLE D-FF SSOP8
5
U4 U9 U10 U15 U16
TEXAS INSTRUMENTS
SN74LVC2G74DCTR
50
060-00062-01
A
IC LNR, V REG, LNOISE 500mA SO8-150
4
U5 U6 U7 U8
LINEAR TECH
LT1763CS8
51
065-00178-Z1
E
IC CRUS LOW V AMP DC-1kHz NPb SOIC8
1
U11
CIRRUS LOGIC
CS3011-ISZ/E
ECO259 ECO316
52
060-00162-01
A
IC 3.3V U LOW PWR RS485 XCVR SOIC8
4
U12 U13 U17 U18
LINEAR TECH
LTC1480IS8
53
060-00236-01
A
IC LNR PRC V REF 2.5V TC10 SO8-150
1
U14
LINEAR TECH
LT1019AIS8-2.5
54
065-00228-Z2
A0
IC CRUS LNSE DIDO AMP NPb SSOP24
2
U19 U219
CIRRUS LOGIC
CS3301A-ISZ/A0
ECO546
55
065-00230-Z2
A0
IC CRUS LPWR 2CH MOD NPb SSOP24
2
U20 U520
CIRRUS LOGIC
CS5372A-ISZ/A0
ECO262, ECO546
56
065-00173-Z1
D
IC CRUS TEST DAC SSOP28 NPb
1
U21
CIRRUS LOGIC
CS4373A-ISZ/D
ECO262
57
065-00056-01
A
IC CRUS QUAD DIG FILTER TQFP64
1
U22
CIRRUS LOGIC
CS5376A-IQ/A
58
060-00067-01
A
IC LNR DUAL CMOS SW DEBNCR SOT223-6
2
U23 U26
MAXIM
MAX6817EUT-T
59
061-00064-01
A
IC LOG, HEX INVERTER SO14-150
1
U24
TEXAS INST
SN74LVC04AD
60
062-00022-01
A
IC PGM EEPROM 8kX8 SPI SRL SOIC8
1
U25
ATMEL
AT25640N-10SI-2.7
NOT PROGRAMMED BEFORE ASSEMBLED, PROGRAMMED AT TEST
