4. BILL OF MATERIALS
CIRRUS LOGIC CDB5378_Rev_C1.bom
BILL OF MATERIAL (Page 1 of 3)
Item
Cirrus P/N
Re
v
Descri
p
tion
Qt
y
Reference Desi
g
nato
r
MFG
MFG P/N
Notes
1
004-00068-Z1
A
CAP 4.7uF ±10% 10V NPb TANT CASE A
2
C1 C59
KEMET
T491A475K010AS
2
001-04345-Z1
A
CAP 0.1uF ±10% 50V X7R NPb 0805
44
C2 C11 C12 C13 C15 C16 C24 C25 C26 C27 C30 C31 C32 C33 C34 C36 C44 C45 C48 C49 C51 C52 C54 C55 C57 C60 C61 C62 C65 C66 C67 C68 C70 C71 C72 C73 C74 C75 C76 C77 C78 C79 C80 C81
KEMET
C0805C104K5RAC
3
001-04076-Z1
A
CAP 0.01uF ±10% 50V NPb X7R 0805
8
C3 C4 C5 C9 C10 C14 C22 C23
KEMET
C0805C103K5RAC
4
004-00102-Z1
A
CAP 100uF ±10% 16V TANT NPb CASE D
9
C6 C7 C8 C18 C19 C20 C28 C29 C35
KEMET
T491D107K016AS
5
001-06603-Z1
A
CAP 0.01uF ±5% 25V C0G NPb 1206
8
C37 C38 C39 C40 C41 C46 C47 C50
KEMET
C1206C103J3GAC
6
000-00009-Z1
A
NO POP CAP NPb 1206
0
C53 C56 C58
NO POP
NP-CAP-1206
DO NOT POPULATE
7
070-00004-Z1
A
DIODE SCHTTKY BARR 30V 0.2A NPb AXL
4
D1 D2 D3 D4
PHILIPS
BAT85
8
070-00024-Z1
A
DIODE SWT 70V 215mA NPb SOT-23
4
D5 D6 D7 D8
ON SEMICONDUCTOR
BAV99LT1G
9
070-00055-Z1
A
DIODE ARRAY 5V (TVS) ESD NPb SOT143
1
D
9
LITTELFUSE
SP0503BAHTL
10
165-00004-Z1
A
LED SUP RED 1.7V 1mA 1.6MCD NPb SMD
1
D10
CHICAGO MINIATURE
CMD28-21SRC/TR8/T1
11
115-00014-Z1
A
HDR 2x1 ML .1" 062BD ST GLD NPb TH
0
J
1
SAMTEC
TSW-102-07-G-S
DO NOT POPULATE
12
110-00028-Z1
A
CON BNC-PCB RCPT NPb RA
1
J
4
KINGS
KC-79-237 M06
13
115-00014-Z1
A
HDR 2x1 ML .1" 062BD ST GLD NPb TH
2
J5 J56
SAMTEC
TSW-102-07-G-S
14
130-00007-Z1
A
JACK BAN SOLDR TERM NYL INS GRN NPb
1
J
6
JOHNSON COMPONENTS
108-0904-001
REQUIRES BINDING POST HOOK UP WIRE. L 1.500 X 0.250T X 0.250T TYPE E 24/19 BLU SQUIRES ELEC. INC.
15
130-00009-Z1
A
JACK BAN SOLDR TERM NYL INS YLW NPb
1
J
7
JOHNSON COMPONENTS
108-0907-001
REQUIRES BINDING POST HOOK UP WIRE. L 1.500 X 0.250T X 0.250T TYPE E 24/19 BLU SQUIRES ELEC. INC.
16
130-00014-Z1
A
JACK BAN SOLDR TERM NYL INS BLK NPb
1
J
8
JOHNSON COMPONENTS
108-0903-001
REQUIRES BINDING POST HOOK UP WIRE. L 1.500 X 0.250T X 0.250T TYPE E 24/19 BLU SQUIRES ELEC. INC.
17
130-00006-Z1
A
JACK BAN SOLDR TERM NYN INS RED NPb
1
J
9
JOHNSON COMPONENTS
108-0902-001
REQUIRES BINDING POST HOOK UP WIRE. L 1.500 X 0.250T X 0.250T TYPE E 24/19 BLU SQUIRES ELEC. INC.
18
115-00016-Z1
A
HDR 3x2 ML .1"CTR 062 S GLD NPb
3
J10 J11 J21
SAMTEC
TSW-103-07-G-D
19
115-00013-Z1
A
HDR 2x2 MLE .1"CTR .062BD S GLD NPb
8
J12 J13 J19 J22 J23 J33 J34 J43
SAMTEC
TSW-102-07-G-D
20
115-00012-Z1
A
HDR 4x2 MLE .1"CTR S GLD NPb
6
J14 J15 J24 J25 J40 J58
SAMTEC
TSW-104-07-G-D
21
115-00029-Z1
A
HDR 8x2 ML .1" 062BD ST GLD NPB TH
3
J16 J17 J18
SAMTEC
TSW-108-07-G-D
22
115-00011-Z1
A
HDR 10x2 ML .1" 062BD ST GLD NPb TH
0
J26 J44 J46 J52 J53 J54 J55 J61 J62
SAMTEC
TSW-110-07-G-D
DO NOT POPULATE
23
115-00061-Z1
A
HDR 12x2 ML .1" CTR 062 S GLD NPb
1
J27
SAMTEC
TSW-112-07-G-D
24
115-00061-Z1
A
HDR 12x2 ML .1" CTR 062 S GLD NPb
0
J28 J35
SAMTEC
TSW-112-07-G-D
DO NOT POPULATE
25
115-00023-Z1
A
HDR 14x2 ML .1"CTR 062 S GLD NPb
0
J30 J31 J37 J38
SAMTEC
TSW-114-07-G-D
DO NOT POPULATE
26
110-00055-Z1
A
CON TERM BLCK 4 POS 5mm C/C NPb BLU
2
J32 J41
ON-SHORE TECHNOLOGY
ED 100/4DS
27
115-00176-Z1
A
HDR 7x2 ML 2MM CTR 062BD S GLDTHNPb
1
J39
MOLEX
87758-1416
28
115-00012-Z1
A
HDR 4x2 MLE .1"CTR S GLD NPb
0
J45
SAMTEC
TSW-104-07-G-D
DO NOT POPULATE
29
110-00041-Z1
A
CON RA USB BLK NPb
1
J47
AMP
292304-1
30
110-00056-Z1
A
CON TERM BLCK 2 POS 5mm C/C NPb BLU
3
J50 J59 J63
ON-SHORE TECHNOLOGY
ED 100/2DS
31
115-00003-Z1
A
HDR 5x2 MLE .1"CTR S GLD NPb
1
J60
SAMTEC
TSW-105-07-G-D
