Verify the correct communications port and that the cable is attached to the "Computer" connection on the
pump.

If the Basic communications mode is used, check if the pump is in Safe communications mode. See section
8.3, “RS-232 Protocol”, for instructions on how to change the communications mode.

Verify the pump’s network address.

Pusher block makes a snap or click sound when the pump is started: This is a normal condition. When
the pusher block is manually moved, the drive-nut may not have been fully engaged on the drive screw. The
sound heard is the drive-nut engaging on the drive screw.

Pump doesn’t stop after dispensing a set volume: The pump was previously setup with a multiple Phase
Pumping Program. To simply dispense a fixed volume at a fixed pumping rate, the second Program Phase
must be the ‘Stop’ function. See section 7.1, How to Enter Pumping Programs, for instructions on changing the
Pumping Program.

Pump stops pumping after a period of time: A dispense volume has been set. Verify that the dispense
volume is set to 0.

10.5 Specifications

10.5.1 Mechanical & Electrical

Syringe sizes:

Up to 60 mL. 140 mL partially filled

Number of syringes:

Motor type:

Step motor

Motor steps per revolution:

400

Microstepping:

1/8 to 1/2 depending on motor speed

Advance per step:

0.2126 uM to 0.8504 uM depending on motor speed

Motor to drive screw ratio:

15/28

Drive screw pitch:

20 revolutions/”

DC connector:

2.5 mm, center positive

Voltage at DC connector:

12V DC at full load

Amperage:

1000 mA at full load

Power supply type:

Unregulated linear external wall adapter, country and power
source specific

Power supply output rating:

12V DC @ 1000 mA

Dimensions:

8 3/4” x 5 3/4” x 4 1/2” High
(22.86 cm x 14.605 cm x 11.43 cm)

Weight:

3.6 lbs. (1.63 kg)

10.5.2 Operational

Maximum speed:

18.36964 cm/min

Minimum speed:

0.008409 cm/hr

Maximum pumping rate:

6120 ml/hr with a B-D 60 cc syringe

Minimum pumping rate:

1.459

l/hr with a B-D 1 cc syringe

Maximum force:

100 lbs. at minimum speed, 18 lbs. at maximum speed

Number of Program Phases:

RS-232 pump network:

100 pumps maximum

RS-232 selectable baud rates:

300, 1200, 2400, 9600, 19200

Syringe inside diameter range:

0.100 to 50.00 mm
