TTL INPUT QUERY
IN
E { 1 |2 | 3 | 4 | 5 }
Expansion Port Connector
Queries TTL level of pin on ‘TTL I/O’ connector. Set is not applicable.
Valid values: 2, 3, 4, and 6.
E Reads from Expansion Port I/O connector on PCB.
Query response:
BUZZER
BUZ [ 0 | { 1 [ < n > ] } ]
Sets / queries buzzer
Set:
0 = Turn buzzer off;
1 = Turn buzzer on
if
If
otherwise buzzer beeps
if
Query response: { 0 | 1 }
0 = Buzzer off
1 = Buzzer is on continuously or beeping.
8.5.5 System Commands
SET PUMP NETWORK ADDRESS AND BAUD RATE
* ADR [
[DUAL | RECP]
Set/query pump network address
=>Valid range: 0 to 99
B { 19200 | 9600 | 2400 | 1200 | 300 } will change the baud rate as indicated. NOTE: The command
response and all further communications will be at the specified baud rate.
DUAL Sets the pump to Dual Pumping mode with a secondary pump.
RECP
Sets the pump to Reciprocating Pumping mode with a secondary pump.
With both Dual and Reciprocating modes, the baud rate defaults to 19,200.
This is a special system command that will be accepted by the pump regardless of its current address. Once
set, the pump will only respond to commands with the set address and at the specified baud rate.
Note: Once DUAL or RECP is set, the pump will only respond to commands that are preceded by the ‘*’
character. To exit DUAL or RECP mode, reset the address: * ADR 0
Example: *ADR
Query current address setting
*ADR 3
Set pump network address to 3. The pump will now only respond to
commands with address 3
*ADR 5 B 1200
Set the pump network address to 5 and the baud rate to 1200. The
command response will be at 1200 baud
