3. Specifications
3. Specifications
Limits for the contact rating with resistive load
Specifications Model 851.3 Model 851.33
Used for instrument type PGS21.1x0, PGS23.1x0, PGS43.1x0,
PGS43HP.1x0, PGS63HP.1x0,
DPGS43.1x0, DPGS43HP.1x0,
APGS43.1x0
Contact design
1 change-over
contact
2 change-over
contacts
Type of contact bistable
Max. switching voltage AC/DC V 250
Min. switching voltage V not required
Max. switching current AC/DC A 1
Min. switching current mA not required
Max. carry current AC/DC A 2
cos ϕ 1
Contact rating W/ VA 60
Contact resistance (static) mΩ 100
Insulation resistance Ω 10 9
Breakdown voltage DC V 1000
Switching time incl.
contact chatter
ms 4.5
Contact material Rhodium
Switch hysteresis % 3 ... 5
The ingress protection to EN 60529 against external influences depends
on the basic instrument and is found in the respective data sheet.
The limit switches can be used in the range from -20 to +70 °C. Where
the permissible temperatures for the basic instrument (see data sheet)
deviate from this range, the lower values are valid.
For further specifications see the corresponding WIKA data sheet and
the order documentation.
