10 WIKA operating instructions pressure transmitter model D-1x-7
2478159.05 12/2011 GB/D/F/E
GB
3. Specifications
Specifications Models D-1x-7
Long-term stability % of span ≤ 0.10 / year (at reference conditions)
Permissible temperature ranges
■ Medium 5) 6) °C -20 ... +80
■ Ambient 5) °C -20 ... +80
■ Storage 5) °C -40 ... +85
Compensated temperature range °C -20 ... +80
Temperature coefficients in the
compensated temperature range
(The temperature errors in the range 0 ... +50 °C are already
included in the accuracy)
■ Mean TC of zero point % of span ≤ 0.20 / 10 K {≤ 0.10 / 10 K}
■ Mean TC of span % of span ≤ 0.20 / 10 K {≤ 0.10 / 10 K}
CE conformity
■ Pressure equipment directive 97/23/EC
■ EMC directive 2004/108/EC, EN 61326 emission (group 1, class B) and
interference immunity (industrial application)
Shock resistance g < 100 per IEC 60068-2-27 (mechanical shock)
Vibration resistance g < 5 per IEC 60068-2-6 (vibration under resonance)
Reverse polarity protection U
B+
vs. U
B-
Weight kg approx. 0.4
{ } Items in curved brackets are optional extras for an additional price.
1) Applies only to model D-10-7.
2) For model D-11-7: The value specified in the table applies only when sealing is made using a sealing ring below the hexagon. Otherwise
max. 1,500 bar applies.
3) Not with model D-10-7 for measuring ranges > 25 bar.
4) Including non-linearity, hysteresis, zero offset and end value deviation (corresponds to measured error per IEC 61298-2). Calibrated in
vertical mounting position with process connection facing downwards.
5) Also meets EN 50178, tab. 7, operation (C) 4K4H, storage (D) 1K4, transport (E) 2K3
6) Model D-11-7 is not available in an oxygen version. Model D-10-7 is only available in an oxygen version with medium temperatures
between -20 … +60 °C.
For special model numbers, e.g. D-10000-7 or D-11000-7, please note the specifications stated on the
delivery note.
For further specifications see WIKA data sheet PE 81.30 and the order documentation.
