VS-4228 - Technical Specifications

Technical Specifications

INPUT/OUTPUT:

8 in/out ports on 9

−pin D−sub (F) connectors

CONTROL:

Front panel buttons, RS

−485 and RS−232 serial interface

(in and out)

INDICATORS:

−character display on the front panel

STANDARDS COMPLIANCE:

TIA/EIA-422-B and SMPTE 207M

OPERATING TEMPERATURE:

0° to +55°C (32° to 131°F)

STORAGE TEMPERATURE:

-45° to +72°C (-49° to 162°F)

HUMIDITY:

10% to 90%, RHL non-condensing

DIMENSIONS:

19” x 7” x 1U (W, D, H) rack-mountable

POWER SOURCE:

230V AC, 50/60 Hz, (115V AC, U.S.A.) 10VA

WEIGHT:

2.2 kg (4.88 lbs) approx

ACCESSORIES:

Power cord, Windows® Control Software

Specifications are subject to change without notice at
