VS-311H - Connecting the VS-311H 7
4 Connecting the VS-311H
Always switch off the power to each device before connecting it to your
VS-311H. After connecting your VS-311H, connect its power and then
switch on the power to each device.
To connect the VS-311H as illustrated in the example in Figure 2 :
1. Connect an HDMI source (for example, an HDMI DVD player) to the IN 1
HDMI connector and connect the digital audio input to the IN 1 S/PDIF RCA
connector.
You can also connect a DVD player with a DVI connector, using a DVI-HDMI adapter to
transfer video signals. Alternatively you can connect analog audio to the 3.5 mini-jack
connector
2. Connect an HDMI source (for example, an HDMI set top box source) to the
IN 3 HDMI connector and connect the digital audio input to the IN 3 3.5 mini-
jack connector or you can connect it to the S/PDIF RCA connector.
3. Connect the OUT HDMI connector to the HDMI acceptor (for example, an
HDMI plasma display).
4. Connect the AUDIO OUT S/PDIF RCA connector and the AUDIO OUT 3.5
mini-jack connector to a digital audio acceptor (for example, an AV receiver).
If the inputs are connected only to the 3.5 mini-jack connectors, connect the AUDIO
OUT 3.5 mini-jack connector and/or the BALANCED OUT terminal block connector
only.
5. Set the PRIORITY SETUP DIP-switches (see Section 4.1 )
6. If required, connect a PC and/or controller to the RS-232 port (see
Section 4.4 ) and/or the ETHERNET port (see Section 4.5 ).
7. If required, connect the contact closure remote control PINs (see Section 4.3 ).
8. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in Figure 2 ).
